Secure Boot and Hardware Trust: The Foundation of Security (Part 5)

Share:

Trust Must Start Somewhere

secure-boot uefi tpm trusted-computing firmware-security

Trust Must Start Somewhere

Throughout this series, we’ve explored attacks at every level—buffer overflows, privilege escalation, rootkits. But all our defenses assume one thing: the operating system itself is trustworthy.

What if it isn’t? What if a bootkit modifies the OS before it even loads? What if firmware is compromised?

Secure Boot and Hardware Trust address this fundamental question: How do we establish a chain of trust from the first instruction?

---

The Boot Process

Before understanding Secure Boot, we need to understand what happens when you press the power button.

Legacy BIOS Boot

[Power On]
    ↓
[BIOS] (Firmware)
    ↓
[MBR] (Master Boot Record - first 512 bytes of disk)
    ↓
[Bootloader] (GRUB, Windows Boot Manager)
    ↓
[OS Kernel]
    ↓
[User Space]

Problem: No verification at any step. Malware can infect MBR or bootloader.

UEFI Boot

[Power On]
    ↓
[UEFI Firmware]
    ↓
[EFI System Partition] (FAT32 partition with bootloaders)
    ↓
[Bootloader] (.efi executable)
    ↓
[OS Kernel]
    ↓
[User Space]

UEFI is more sophisticated, but still doesn’t verify integrity by default.

---

Secure Boot

Secure Boot uses cryptographic signatures to verify each boot component before execution.

How It Works

1. Platform Key (PK): Root of trust, typically OEM’s key.
2. Key Exchange Keys (KEK): Can modify signature database.
3. Signature Database (db): Allowed signatures/hashes.
4. Forbidden Signature Database (dbx): Blocked signatures.

Boot Verification Process

[UEFI Firmware]
    |
    | "Is bootloader signed by key in db?"
    ↓
[Verify Signature] ──No──→ BOOT BLOCKED
    |
   Yes
    ↓
[Bootloader Executes]
    |
    | "Is kernel signed?"
    ↓
[Verify Signature] ──No──→ BOOT BLOCKED
    |
   Yes
    ↓
[Kernel Executes]

Certificate Chain

Platform Key (PK)
    ↓ Signs
Key Exchange Key (KEK)
    ↓ Signs
Signature Database Entry (db)
    ↓ Contains
Microsoft Windows Production CA
    ↓ Signs
Windows Boot Manager

---

Linux and Secure Boot

Linux distributions support Secure Boot through shim—a small bootloader signed by Microsoft.

The Shim Process

[UEFI] → [Shim (Microsoft signed)]
              ↓
         [GRUB (Distribution signed)]
              ↓
         [Kernel (Distribution signed)]

Enrolling Custom Keys

For custom kernels or distributions:

# Generate your own keys
openssl req -new -x509 -newkey rsa:2048 -keyout MOK.key -out MOK.crt -days 365

# Sign kernel
sbsign --key MOK.key --cert MOK.crt --output vmlinuz-signed vmlinuz

# Enroll Machine Owner Key
mokutil --import MOK.crt
# Reboot and complete enrollment in MOK Manager

---

Trusted Platform Module (TPM)

The TPM is a dedicated security chip that provides hardware-based security functions.

TPM Capabilities

1. Secure Key Storage: Private keys never leave the TPM.
2. Platform Configuration Registers (PCRs): Measure boot components.
3. Random Number Generation: True hardware RNG.
4. Sealing/Unsealing: Encrypt data bound to platform state.

Platform Configuration Registers

PCRs store cryptographic hashes of boot components:

PCR	Measures
0	BIOS/UEFI firmware
1	BIOS/UEFI configuration
2-3	Option ROMs
4	MBR/Boot Manager
5	GPT/Partition Table
7	Secure Boot State
8-15	OS-defined

Measured Boot

Unlike Secure Boot (which blocks unauthorized code), Measured Boot records what runs without blocking.

[UEFI Firmware]
    ↓ Extend PCR[0] with hash of firmware
[Bootloader]
    ↓ Extend PCR[4] with hash of bootloader
[Kernel]
    ↓ Extend PCR[8] with hash of kernel
[Result: PCR values reflect exact boot path]

Remote Attestation

A remote server can verify your system’s integrity:

1. Your system sends TPM quote (signed PCR values).
2. Server compares against known-good values.
3. If PCRs match expected values → system is trustworthy.
4. If PCRs differ → something changed (potentially compromised).

---

BitLocker and TPM

Windows BitLocker uses TPM to protect disk encryption keys.

TPM-Only Mode

[Boot] → [TPM verifies PCRs]
              ↓ PCRs match expected
         [TPM releases encryption key]
              ↓
         [Disk decrypted, OS loads]

If a bootkit modifies the boot process, PCR values change, and the TPM refuses to release the key.

TPM + PIN

Adds a PIN requirement for additional security.

---

Attacks Against Secure Boot and TPM

1. Secure Boot Bypass (BootHole - CVE-2020-10713)

Vulnerability in GRUB2 allowed arbitrary code execution in Secure Boot mode.

Impact: Attacker with local access could install a bootkit.

Mitigation: Update GRUB2, add vulnerable GRUB to dbx.

2. Evil Maid Attack

Physical access attack:

1. Boot from USB.
2. Install bootkit on target disk.
3. Bootkit captures BitLocker PIN on next boot.
4. Return and retrieve captured PIN.

Mitigation: Pre-boot authentication, tamper-evident seals.

3. TPM Reset Attacks

On some systems, TPM can be reset without clearing PCRs, leading to invalid attestation.

4. Cold Boot Attack

RAM retains data briefly after power off. Freeze RAM to extend retention, then dump.

Mitigation: Memory encryption (AMD SME, Intel TME).

5. UEFI Vulnerabilities

Firmware has bugs too. Exploited to persist across OS reinstalls.

Examples: Hacking Team UEFI rootkit, Lojax.

Mitigation: Keep firmware updated, check vendor advisories.

---

Intel Boot Guard

Hardware enforcement of Secure Boot at the CPU level.

How It Works

1. OEM fuses their public key hash into CPU.
2. First instruction executed is verified against this key.
3. Cannot be modified—permanent at manufacturing.

Advantage: Even firmware updates can’t disable. Disadvantage: Only OEM can sign firmware—no custom firmware.

---

AMD Platform Secure Boot (PSB)

AMD’s equivalent to Intel Boot Guard.

• Uses AMD Secure Processor.
• Verifies firmware signature before CPU executes.
• OEM-controlled keys.

---

Modern Security Features

Intel TXT (Trusted Execution Technology)

Creates a measured, verified execution environment.

AMD SEV (Secure Encrypted Virtualization)

Encrypts VM memory—even hypervisor can’t read it.

ARM TrustZone

Separates “secure world” from “normal world” at hardware level.

Confidential Computing

Protect data in use with hardware-based Trusted Execution Environments (TEE).

---

Implementing Secure Boot (Practical)

Verifying Secure Boot Status

Linux:

mokutil --sb-state
# SecureBoot enabled

# Check enrolled keys
mokutil --list-enrolled

Windows:

Confirm-SecureBootUEFI
# True

# Check Secure Boot policy
Get-SecureBootPolicy

Checking TPM

Linux:

# TPM 2.0
cat /sys/class/tpm/tpm0/device/description

# Check PCR values
tpm2_pcrread

Windows:

Get-Tpm
# TpmPresent: True
# TpmReady: True
# TpmEnabled: True

---

Best Practices

For Organizations

1. Enable Secure Boot on all systems.
2. Deploy TPM-based disk encryption.
3. Implement measured boot with remote attestation.
4. Keep firmware updated—include in patch management.
5. Physical security for high-value assets.

For Developers

1. Sign your bootloaders and kernels.
2. Use TPM for key storage where possible.
3. Leverage hardware security (TEE, SGX, SEV).

---

Summary

• Secure Boot cryptographically verifies boot components.
• TPM provides hardware-rooted trust through measurement and key storage.
• Measured Boot records the boot chain for later attestation.
• Attacks exist but hardware trust raises the bar significantly.
• Defense in depth: Combine Secure Boot + TPM + disk encryption + firmware updates.

This concludes the System Security series. We’ve journeyed from protection rings through buffer overflows, privilege escalation, rootkits, and now hardware trust. Understanding these fundamentals is essential for any security professional.

Tharunaditya’s Security Note: Hardware security isn’t magic—it’s just a higher bar. But that higher bar matters. When attackers need physical access or zero-days in firmware, you’ve already filtered out most threats.
